The packing machine type "XAG-44"

Packaging machine type "XAG-44" It is used for thermoforming mugs made of foil (PVC, polystyrene, etc.), closing with a covering foil (heat-sealing) by sealing, punching and transporting the filled cups. Overall dimensions (maximum): - Length - 6,610 mm; - Width - 2,140 mm; - Height - 2,185 mm. Technical data: - Cup format (LxW) - 95 x 95 mm; - The height of the cup - 97 mm; - Bottom foil (for cups) - PVC or polystyrene; - Die length - 315 mm; - Die width - 230 mm; - Die thickness - 100 mm; - The width of the bottom foil - 343 mm; - Thickness of the bottom foil - 0.4-0.9-1 mm; - Cover foil - heat-weldable; - The width of the upper foil - 311 mm; - Thickness of the upper foil - 0.03-0.04 mm; - Film travel - 206 mm; - Capacity - 12-14 tacts; - Pressure of the stamp - 3.000 N; - Mold clamping force on the forming station - 22,000 N; - Punching force - 75,000 N; - Compressed air pressure - 8-10 bar; - Compressed air consumption - 90 m³ / h; - Cooling water consumption - 1.2 m³ / h; - Power supply - 3 x 380 V / 220 V; - Heater power - 12.5 kW; - Power of 4 electric motors (including the dispenser) - 5.2 kW; - Weight - 2,050 kg. A dispenser for thick and semi-liquid products. It is an independent device added to the packing machine.

The dispenser has 6 piston dosing heads with product tray. Technical data of the dispenser: - 6 doses with a diameter of 70 mm each; - dosing depth - 130 mm. Overall dimensions of the dispenser: - length - 1,100 mm; - width - 1,200 mm; - height - 1,850 mm. Container overall dimensions: - length - 900 mm; - width - 380 mm; - depth - 460 mm.
